Bosch DWB96DM50B Brushed Steel 90Cm Chimney Hood
- ColourBrushed steel
- Energy RatingB
- Manufacturer Guarantee2 years
- EAN4242005051120
DWB96DM50B - Series 4 Wall-mounted cooker hood 90 cm Stainless steel
Technical Overview
Installation typology: Wall-mounted
Width: 90 cm
Colour of appliance: Stainless steel
Sound power at max. speed (2010/30/EC): 60 dB
Max. air extraction: 372 m³/h
Boost position air extraction: 604 m³/h
Air circulation: Convertible
Home Connect ¹: No
¹ Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
Key Features
The super-quiet hood.
Our hoods are especially silent, advanced noise reduction technology, including insulated motor housing and optimised airflow design, significantly reduce noise levels. This ensures that your kitchen remains an undisturbed space, allowing you to cook, converse, and entertain without any disruptions. Perfect for kitchen diners and open-plan areas – you'll hardly even know the hood is on!
Ultra-efficient hood control.
Have complete control of your kitchen. The Touch Select Control feature features a sleek and user-friendly touch interface. With just a gentle swipe or tap, you can easily adjust the fan speed, activate different ventilation modes, and control the lighting of your hood. It's a seamless and intuitive experience that puts you in complete control.
Power Boost for Bosch Downdraft Ventilation
Our Intensive Speed Setting feature provides a powerful boost to the ventilation system, rapidly extracting and eliminating cooking fumes and odours. With just a touch of a button, you can activate this turbocharged mode, ensuring a fresh and clean kitchen environment in no time.
Metal grease filter
Ducted and recirculation hoods require metal grease filters to filter grease and other solid particles out of the extracted air. To keep these filters operating at maximum efficiency, clean them about once a month either by hand or in the dishwasher.
Deal with whatever steam comes your way.
Now it is easy to keep control in the kitchen. The Intensive speed setting with reset quickly increases the extraction rate to match whatever steam is coming its way. And thanks to the integrated self-timer, which automatically reduces the rate after a few minutes, you can stay focused on cooking.
Special Features
● Especially silent: maximum hood performance, minimum noise.
● TouchSelect control: Quickly select hood settings via touch.
● LED Illumination: The energy-saving lighting provides bright and clear lighting for the hob area.
● Intensive speed setting: removes strong kitchen odours quickly and effectively.
● High extraction rate - for continuously clean air in the kitchen.
| Specifications | ||
|---|---|---|
| - General | ||
| Width | 90 cm | |
| Colour | Stainless steel | |
| Installation typology | Wall-mounted | |
| Air circulation | Convertible | |
| Total power of the motors | 215 W | |
| Type of control setting devices | LED, touch control | |
| Number of speed settings | 3-stages + intensive setting | |
| Max. air extraction | 372 m³/h | |
| Boost position air extraction | 604 m³/h | |
| Sound power at max. speed (2010/30/EC) | 60 dB | |
| Sound power boost (2010/30/EC) | 70 dB | |
| Max. air recirculation | 337 m³/h | |
| Boost position output recirculating | 441 m³/h | |
| Sound power at max. speed (recirculation) | 70 dB | |
| Sound power boost (recirculation) | 74 dB | |
| Grease filter material | Washable aluminium | |
| Energy efficiency rating | B | |
| Total annual energy consumption | 48.5 kWh/annum | |
| - Dimensions | ||
| Height of the appliance | 53 mm | |
| Width of the appliance | 900 mm | |
| Depth | 500 mm | |
| Height of the chimney | 583-912/583-1022 mm | |
| Minimum distance above an electric hob | 550 mm | |
| Minimum distance above a gas hob | 650 mm | |
| Diameter of air outlet | 120 / 150 mm | |
| No-return airflow flap | No | |
| Length electrical supply cord | 130.0 cm | |
| Net weight | 12.7 kg | |
| Handle bar | Not applicable | |
| Appliance height exhaust air max | 965 mm | |
| Appliance height exhaust air min | 635 mm | |
| Appliance height recirculating max | 1075 mm | |
| Appliance height recirculating min | 635 mm | |
| - Comfort | ||
| PrefectAir Sensor | No | |
| Cooktop-based hood control | No | |
| EcoSilence Drive - efficient and extra silent | No | |
| Silence | No | |
| Clean filter reminders | No | |
| Boost position | Yes | |
| Delay Shut off modes | No | |
| Remote control | No | |
| - Light | ||
| Type of lamps used | LED | |
| Number of lights | 2 | |
| Total luminance | 214 lm | |
| Colour temperature | Neutral (3.500 K) | |
| Illumination type softlight | No | |
| Color temperature control via smartphone with Home Connect | No | |
| emotionLight Pro | No | |
| - Connectivity | ||
| Home Connect ¹ | No | |
| Power consumption standby/display off | 0.3 W | |
| - Notes | ||
| ¹ | Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com. |
| Manufacturer | Bosch |
|---|---|
| GTIN | 4242005051120 |
| Colour | Brushed Steel |
| Model Number | DWB96DM50B |
| Energy Rating | B |
| Expired Status | No |
